Main Technical Parameters
| Bucket | 20m3 | Capacity | 40000kg |
| Unloading Height | 5923mm | Min. Ground Clearance | 397mm |
| Oscilation Angle | ±10° | Max torque | 2757Nm / 1260rpm |
| Speed | 0-35.2km/h | Climing Ability | 20° |
| Traction | 404KN | OperationWeight | 36800kg |
Main Configuration
Engine：VOLVO TAD1650VE/ 405kw / 1900rpm
Torque Converter：DANA CL8000
Transmission：DANA 8000
Axle：DANA53R300, Rigid Planetary Axle
Hydraulic Pump：Gear Type
Wheel & Tire：TECHKING 29.5R25 ETNT
