Operating Weight

kg

1300

Bucket capacity

m³

0.03

Overall Dimension

L / W / H

2800x1100x2200

Engine Brand

Laidong / Yanmar

Engine Model

385 / 3TNV70

Engine Type

Water cooled

No. of cylinders

3 cylinder

Engine Power

kw

18.1 / 10

Pump

Gear pump

Max.travel speed

km/h

2-4

Swing speed

r/min

12

Bucket digging force

kN

13.5

Bucket arm digging force

kN

10.1

Working pressure

Mpa

18

Length of track

mm

1300

Width of track

mm

180

Max. Digging radius

mm

2400

Max. Digging depth

mm

1800

Max. Digging height

mm

2740

Max. Dumping height

mm

1750

Height of bulldozer blade

mm

345

Depth of bulldozer blade

mm

255
