Operating Weight

kg

2200

Bucket capacity

m³

0.1

Overall Dimension

L / W / H

4170x1300x2270

Engine Brand

Laidong / Kubota

Engine Model

3TE30 / D1105

Engine Type

Water cooled

No. of cylinders

3 cylinder

Engine Power

kw

22.1 / 14.2

Max.travel speed

km/h

2.8

Swing speed

r/min

12

Bucket digging force

kN

11.5

Bucket arm digging force

kN

9.3

Working pressure

Mpa

16

Length of track

mm

1630

Width of track

mm

250

Max. Digging radius

mm

4350

Max. Digging depth

mm

2500

Max. Digging height

mm

3700

Max. Dumping height

mm

2330

Height of bulldozer blade

mm

310

Depth of bulldozer blade

mm

240
