Operating Weight

kg

4200

Bucket capacity

m³

0.17

Overall Dimension

L / W / H

5500x1750x1861

Engine Brand

Xincha /Yanmar

Engine Model

490 / 4TNV88

Engine Type

Water cooled

No. of cylinders

4  cylinder

Engine Power

kw

36.8 / 25.2

Max.travel speed

km/h

2.7 / 4.4

Swing speed

r/min

10

Bucket digging force

kN

23.7

Bucket arm digging force

kN

21.6

Working pressure

Mpa

22

Length of track

mm

2190

Width of track

mm

350

Max. Digging radius

mm

4730

Max. Digging depth

mm

2545

Max. Digging height

mm

4450

Max. Dumping height

mm

3050

Height of bulldozer blade

mm

359

Depth of bulldozer blade

mm

268
