Operating weight

KG

4000

Length

mm

5600

Width

mm

1900

Height

mm

2720

Wheel base

mm

2250

Wheel track

mm

1400

Tire size

20.5-16

Max. driving speed

km/h

30

Rated load

KGS

1600

Bucket capacity range

m³

0.7-1.0

Standard bucket capacity

m³

0.7

Bucket width

mm

1900

Dumping height

mm

3200

Dumping reach

mm

800

Max. raising height

mm

4030

Transmission type

Automatic

Control lever

1

Engine model

YUNNEI 490 Turbo

Power

kw

58

Number of cylinder

4

Control type

mechanical

Drive bridge tyre

wheel hub reduction
