Operating weight

KG

4900

Length

mm

6200

Width

mm

2000

Height

mm

2780

Wheel base

mm

2400

Wheel track

mm

1580

Tire size

16/70-20

Max. driving speed

km/h

30

Rated load

KGS

1800

Bucket capacity range

m³

0.7-1.2

Standard bucket capacity

m³

0.7

Bucket width

mm

2000

Dumping height

mm

3500

Dumping reach

mm

900

Max. raising height

mm

5000

Transmission type

Automatic

Control lever

1

Engine model

YUNNEI 4102 Turbo

Power

kw

76

Number of cylinder

4

Control type

mechanical

Drive bridge tyre

big wheel hub reduction
