Operating weight

KG

6000

Length

mm

6600

Width

mm

2050

Height

mm

2860

Wheel base

mm

2780

Wheel track

mm

1670

Tire size

16/70-20

Max. driving speed

km/h

30

Rated load

KGS

2000

Bucket capacity range

m³

0.7-1.5

Standard bucket capacity

m³

0.75

Bucket width

mm

2000

Dumping height

mm

3600

Dumping reach

mm

950

Max. raising height

mm

5300

Transmission type

Automatic

Control lever

1

Engine model

YUCHAI4102 Turbo

Power

kw

78

Number of cylinder

4

Control type

pilot

Drive bridge tyre

big wheel hub reduction
