Operating weight

KG

9600

Length

mm

7200

Width

mm

2400

Height

mm

3300

Wheel base

mm

3150

Wheel track

mm

2100

Tire size

17.5-25

Max. driving speed

km/h

35

Rated load

KGS

3000

Bucket capacity range

m³

1.5-1.8

Standard bucket capacity

m³

1.8

Bucket width

mm

2400

Dumping height

mm

3800

Dumping reach

mm

1200

Max. raising height

mm

5600

Transmission type

Automatic

Control lever

1

Engine model

DONGFANGHONG 6105T/WEICHAI Deutz

Power

kw

92

Number of cylinder

6

Control type

pilot

Drive bridge tyre

big wheel hub reduction
